235N Stroke 85mm UR 5 Collaborative Robot Gripper

Product Categories

Xiangjing (Shanghai) M&E Technology Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 235N Stroke 85mm UR 5 Collaborative Robot Gripper
Brand: robotiq
Price: 1 USD

Brand Name : robotiq

Model Number : 2F-85

Certification : CE EAC

Place of Origin : Canada

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 999 sets/ month

Delivery Time : 15 days

Packaging Details : cartons

Stroke (adjustable) : 85 mm

Friction grip payload : 5 kg

Gripper mass : 0.9 kg

Grip force (adjustable) : 20 to 235 N

Ingress protection (IP) rating : IP40

Contact Now

robotiq 2F-85 robot gripper combine with UR 5 collaborative robot directly on sixth axis robot arm

Main Specifications

Model: 2F-85 robotic gripper
Stroke (adjustable): 85 mm
Friction grip payload : 5 kg
Gripper mass : 0.9 kg
Ingress protection (IP) rating :IP40

Product Description

Production Name	robotiq 2F-85 robot gripper combine with UR 5 collaborative robot directly on sixth axis robot arm
Model	2F-85 robotic gripper
Application	robotic gripper
Stroke (adjustable)	85 mm
Form-fit grip payload	5 kg
Friction grip payload	5 kg
Grip force (adjustable)	20 to 235 N
Gripper mass	0.9 kg
Position resolution (fingertip)	0.4 mm
Ingress protection (IP) rating	IP40
Closing speed (adjustable)	20 to 150 mm/s
Communication protocol	Modbus RTU (RS-485)

235N Stroke 85mm UR 5 Collaborative Robot Gripper

Detailed Images

235N Stroke 85mm UR 5 Collaborative Robot Gripper

UR 5 Collaborative Robot Gripper
